- Large top plate and raceways combine ease of swiveling and strength
- Full double level ball bearing heat treated swivel raceway and high
or low temperature lubricating oil applied
- Axle：20mm diameter axle and lock nut
- Applications: Large platform trucks , freight terminal trucks,drying
racks.
|
|
 |
 |
|
|
|
 |
|
|
|
| 152 |
64 |
RUBBER/CAST IRON |
BALL |
225 |
121 |
194 |
CF1060-01-RCB |
CF1060R-01-RCB |
| 64 |
POLYURETHANE/CAST IRON |
BALL |
500 |
CF1060-01-UCB |
CF1060R-01-UCB |
| 203 |
64 |
RUBBER/CAST IRON |
BALL |
365 |
159 |
241.3 |
CF1080-01-RCB |
CF1080R-01-RCB |
| 64 |
POLYURETHANE/CAST IRON |
BALL |
600 |
CF1080-01-UCB |
CF1080R-01-UCB |
| 254 |
64 |
RUBBER/CAST IRON |
BALL |
400 |
190 |
292 |
CF1010-02-RCB |
CF1010R-02-RCB |
| 64 |
POLYURETHANE/CAST IRON |
BALL |
750 |
CF1010-02-UCB |
CF1010R-02-UCB |
| 300 |
64 |
RUBBER/CAST IRON |
BALL |
400 |
225 |
343 |
CF1012-02-RCB |
CF1012R-02-RCB |
| 64 |
POLYURETHANE/CAST IRON |
BALL |
800 |
CF1012-02-UCB |
CF1012R-02-UCB |
FASTENERS FOR 1000 SERIES
|
| TYPE |
FASTENING SHAPE |
CODE |
SIZE |
| Top Plate |
 |
01 |
OVERALL SIZE：
BOLT HOLE
PATTERN：
ATTACHING BOLT SIZE： |
159*114
133~125*86~62
φ13 |
|
| 02 |
OVERALL SIZE：
BOLT HOLE
PATTERN：
ATTACHING BOLT SIZE： |
180*170
148~144*132~128
φ17 |
|
|
 |
| SPECIAL FINISHES |
| POLISHED GOLD FINISH |
PGF |
| BLACK OXIDE |
BO |
| NICKLE |
N |
| CHROME |
CR |
| SPRAYING |
SR |
|
![]() |
![]() |
![]() |
