- Top plate and yoke assembly:AISI 1045 drop forged steel
- Large top plate provides ease of stability and strength
- Corrosion-resistant zinc plated finish
- 19mm nut and bolt king pin, 17.2mm diameter axle and lock nut
- Leg thickness:9.14mm.Swivel bearing with 12.7mm steel ball
|
 |
 |
|
|
|
 |
|
|
|
| 101.6 |
70 |
POLYURETHANE/CAST IRON |
BALL |
680 |
88 |
142.9 |
HD7040-01-UCB |
HD7040R-01-UCB |
| 152.4 |
63.5 |
STEEL |
BALL |
680 |
133.3 |
190.5 |
HD7060-01-STB |
HD7060R-01-STB |
| 203.2 |
63.5 |
POLYURETHANE/CAST IRON |
BALL |
720 |
158.75 |
257.2 |
HD7080-01-UCB |
HD7080R-01-UCB |
| 63.5 |
STEEL |
BALL |
720 |
HD7080-01-STB |
HD7080R-01-STB |
| 254 |
63.5 |
POLYURETHANE/CAST IRON |
BALL |
900 |
192.1 |
301.6 |
HD7010-01-UCB |
HD7010R-01-UCB |
| 63.5 |
STEEL |
BALL |
900 |
HD7010-01-STB |
HD7010R-01-STB |
| 304.8 |
63.5 |
POLYURETHANE/CAST IRON |
BALL |
900 |
217.5 |
327 |
HD7012-01-UCB |
HD7012R-01-UCB |
| 63.5 |
STEEL |
BALL |
900 |
HD7012-01-STB |
HD7012R-01-STB |
FASTENERS FOR HD7000 SERIES |
| TYPE |
FASTENING SHAPE |
CODE |
SIZE |
| Top Plate |
 |
01 |
OVERALL SIZE：
BOLT HOLE
PATTERN：
ATTACHING BOLT SIZE： |
159*114
133~125*86~62
φ13 |
|
|
 |
| SPECIAL FINISHES |
| POLISHED GOLD FINISH |
PGF |
| BLACK OXIDE |
BO |
| NICKLE |
N |
| CHROME |
CR |
| SPRAYING |
SR |
|
![]() |
![]() |
![]() |
