PRODUCTS | Light medium duty

FASTENERS FOR 5100 SERIES

TYPE

FASTENING SHAPE

CODE

SIZE

Top Plate

OVERALL SIZE：
BOLT HOLE PATTERN：
ATTACHING BOLT SIZE：

95.3*63.5
68~76*44.5
φ8.25

OVERALL SIZE：
BOLT HOLE PATTERN：
ATTACHING BOLT SIZE：

95.3*114.3
66.7*92.1~76*76
φ9.5

OVERALL SIZE：
BOLT HOLE PATTERN：
ATTACHING BOLT SIZE：

79.4*104.8
44.5*76~60.3*85.7
φ9.5

Threaded stem

20
21
22

Diameter-Teeth*Length
φ5/8-11*28
φ1/2-13*25.4
φ1/2-13*38.1

Round stem

22.2*36.5 with φ7.9 cross drilled hole，23 up

Octagon stem

41B
42

19.1*54 with 3 cross drilled holes
22.2*50.8 with φ7.9 cross drilled hole 25.4 up


76.2	31.8	POLY-U ON POLY-O PVC/PLASTIC THERMAL PLASTIC RUBBER SOFT RUBBER HARD RUBBER POLYOLEFIN POLYOLEFIN	BALL BALL BALL PLAIN PLAIN BOLT BOLT	90 90 90 55 90 70 90	73	100	LM5130--PUB LM5130--PVB LM5130--TPB LM5130--SRP LM5130--HRP LM5130--LPO LM5130-**-HPO	LM5130R--PUB LM5130R--PVB LM5130R--TPB LM5130R--SRP LM5130R--HRP LM5130R--LPO LM5130R-**-HPO
101.6	31.8	POLY-U ON POLY-O PVC/PLASTIC THERMAL PLASTIC RUBBER SOFT RUBBER HARD RUBBER POLYOLEFIN POLYOLEFIN	BALL BALL BALL PLAIN PLAIN BOLT BOLT	100 100 100 75 100 80 100	89	127	LM5140--PUB LM5140--PVB LM5140--TPB LM5140--SRP LM5140--HRP LM5140--LPO LM5140-**-HPO	LM5140R--PUB LM5140R--PVB LM5140R--TPB LM5140R--SRP LM5140R--HRP LM5140R--LPO LM5140R-**-HPO
127	31.8	POLY-U ON POLY-O PVC/PLASTIC THERMAL PLASTIC RUBBER SOFT RUBBER HARD RUBBER POLYOLEFIN POLYOLEFIN	BALL BALL BALL PLAIN PLAIN BOLT BOLT	120 120 120 80 120 90 120	100	157	LM5150--PUB LM5150--PVB LM5150--TPB LM5150--SRP LM5150--HRP LM5150--LPO LM5150-**-HPO	LM5150R--PUB LM5150R--PVB LM5150R--TPB LM5150R--SRP LM5150R--HRP LM5150R--LPO LM5150R-**-HPO
